PT803

Pulse Tube Cryocooler

View all Pulse Tube Cryocoolers
Technical Specifications
Downloads
Contact Sales

Technical Specifications

1.0

PT803

Pulse Tube Cryocooler


Parameter
Cooling Capacity4W @ 20K W/ 8W @ 65K
Base Temperature8K
Cool Down Time60 MIN TO 10K
Cold Head Weight24lb (11kg)
Compressor PackageCP103
Water Cooled Weight165 lb (75kg)
Water Cooled Dimensions18 X 18 X 22in (46 X 46 X 56cm)
Air Cooled Weight176lb (80kg)
Air Cooled Dimensions19 X 22 X 22in (48 X 56 X 56cm)
Power Consumption 60Hz (Input Power)208/230 VAC / 1PH / 3.4kW
Power Consumption 50Hz (Input Power)200 VAC / 1PH / 3.4kW
Cooling Water Requirements1.2 GPM (4.5 LPM) @ 80°F (27°C)
Helium Pressure200 ± 5 PSIG (13.8 ± .34 bar) @ 60Hz
TBD ± 5 PSIG (TBD ± .34 bar) @ 50Hz
Ambient Temperature Range45°F TO 100°F (7°C TO 38°C)

Downloads

2.0

PT803

Pulse Tube Cryocooler

PT803 Cryocooler

Capacity Curve
System Drawing
Cold Head Drawing

Custom Options

Scientific research often requires specialized equipment that has never been built before. We fully understand this, and are happy to build customized solutions for our customers and their unique applications.

Commonly provided customizations include:

  • Conflat Flanges
  • ISO Flanges
  • Gas Feed Throughs
  • Electrical Feed Throughs
  • Recondensing Heat Exchangers
  • Gas Pre-Cooling Tube
Contact Sales
